Technical Overview
Frameset
Frame:
257 AMP Premium Aluminium | Smoothwelded | Integrated Battery | Internal Cable Routing | Powder Coat Finish | Post Mount Disc | 12 x 142mm Thru-Axle
Fork:
257 Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
E-System
Drive Unit:
Bosch Performance Line CX
Battery Pack:
Bosch PowerTube | 625 Wh
Display:
Bosch Kiox
Drive Unit Control:
Bosch Kiox
Charger:
Bosch Compact Charger
Cockpit
Stem:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Handlebar:
BMC LSB 01
Seat
Seatpost:
BMC LSP 02
Saddle:
Selle Royal Vivo
Drivetrain
Crankset:
Miranda Classic x Bosch | Gates CDX
Chainrings:
Gates Belt 113 CDXrings
Cassette:
Gates CDX
Cassette Size:
22T
Chain:
Gates Belt 113 CDX
Shifters:
SHIMANO Alfine (SL-S7000) | Rapidfire Plus
Gears:
1 x 8
Brakes
Brake Levers / Calipers:
TEKTRO HD-EU818 / 817
Rotors:
TEKTRO TR25
Rotor Size (F/R):
180 / 160mm
Wheels
Rims:
SR500
Hubs (F/R):
CL-712 | SHIMANO Alfine 8
Tires:
Pirelli Angel GT | 37mm
Additional Information
Tire Clearance:
42mm
Weight without Pedals:
21.9 Kg
ASTM Classification:
Level 2
System Weight Limit:
120kg
